MX887DHTTR
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH OMNIPOLAR TSOT23
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 8015
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 23
Supplier Device Package TSOT-23-3
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2007
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Omnipolar Switch
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Technology Hall Effect
Voltage - Supply 2.5V~5.5V
Function Omnipolar Switch
Current - Supply (Max) 15μA
Output Type Open Drain
Max Output Current 5mA
Operating Supply Voltage 5V
Max Supply Voltage 5.5V
Min Supply Voltage 2.5V
Operating Supply Current 2mA
Polarization North Pole, South Pole
Current - Output (Max) 5mA
Max Supply Current 15μA
Sensing Method Hall Effect
Test Condition -40°C ~ 85°C
Sensing Range ±6mT Trip, ±0.6mT Release
Compliance
RoHS Status RoHS Compliant
