TLE49761KHTSA1
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR SC59
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.2816
≥1 USD $0.2816
Inventory: 274302
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 1.6mm
Length 3mm
Height Seated (Max) 1.2mm
Technical
Sensing Range 11mT Trip, 5mT Release
Test Condition -40°C ~ 150°C
Polarization South Pole
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 24V
Output Type Open Collector
Current - Supply (Max) 17mA
Function Unipolar Switch
JESD-30 Code R-PDSO-G3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.9mm
Supply Voltage 12V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology Hall Effect
HTS Code 8542.39.00.01
Terminal Finish Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Temperature Compensated
JESD-609 Code e3
Series Automotive, AEC-Q100
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
