TLE49681LHALA1
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP, SSO-3-02
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
Hall Effect Sensor 25mA Bipolar Latch 3.3V/5V/9V/12V/15V/18V/24V Automotive 3-Pin SSO Ammo
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.364
≥1 USD $1.364
≥10 USD $1.0208
≥100 USD $0.816992
≥500 USD $0.74888
≥1000 USD $0.629763
≥3000 USD $0.561678
Inventory: 1151
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 3-SIP, SSO-3-02
Number of Pins 3
Technical
Operating Temperature -40°C~170°C TJ
Packaging Tape & Box (TB)
Published 2010
Series Automotive, AEC-Q100
JESD-609 Code e3
Feature Temperature Compensated
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Omnipolar Switch
Terminal Finish Tin (Sn)
Technology Hall Effect
Voltage - Supply 3V~32V
Function Bipolar Switch
Body Length or Diameter 4.16mm
Body Breadth 1.52 mm
Output Type Open Drain
Polarization South Pole
Current - Output (Max) 25mA
Output Current 25mA
Max Supply Current 2.5mA
Halogen Free Not Halogen Free
Test Condition 25°C
Housing PLASTIC
Sensing Range 2.25mT Trip, -2.25mT Release
Hysteresis 2 mT
Magnetic Field Range-Min -2.25 mT
Magnetic Field Range-Max 2.25 mT
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
