TLE49655MXTSA1
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
IC HALL EFFECT UNIPOLAR SOT23-3
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.135118
≥1 USD $0.135118
≥200 USD $0.052289
≥500 USD $0.050451
≥1000 USD $0.049543
Inventory: 1258
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Body Height 1mm
Technical
Magnetic Field Range-Max 10.4 mT
Magnetic Field Range-Min 2.8 mT
Output Range 0-5mA
Hysteresis 2.5 mT
Housing PLASTIC
Sensors/Transducers Type MAGNETIC FIELD SENSOR,HALL EFFECT
Output Current-Max 5mA
Max Supply Current 1.4mA
Termination Type SOLDER
Operating Supply Voltage 5.5V
Output Type CURRENT OUTPUT
Body Length or Diameter 2.9mm
Min Operating Temperature -40°C
Max Operating Temperature 170°C
Terminal Finish Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Automotive, AEC-Q100
Published 2015
Packaging Tape & Reel (TR)
Physical
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 26 Weeks
