TLE49655MXTMA1
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR SOT23-3
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.26149
≥1 USD $0.26149
≥200 USD $0.101199
≥500 USD $0.09764
≥1000 USD $0.095881
Inventory: 5669
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Technical
Operating Temperature -40°C~170°C TJ
Packaging Tape & Reel (TR)
Published 2015
Series Automotive, AEC-Q100
JESD-609 Code e3
Feature Temperature Compensated
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin (Sn)
Technology Hall Effect
Voltage - Supply 3V~5.5V
Function Unipolar Switch
Current - Supply (Max) 2.5mA
Body Length or Diameter 2.9mm
Body Breadth 1.3 mm
Output Type Open Drain
Max Output Current 5mA
Polarity South Pole
Termination Type SOLDER
Polarization South Pole
Max Supply Current 2.5mA
Sensing Method Hall Effect
Test Condition 25°C
Housing PLASTIC
Sensing Range 10.4mT Trip, 2.8mT Release
Hysteresis 2.5 mT
Output Range 0-5mA
Magnetic Field Range-Min 2.8 mT
Magnetic Field Range-Max 10.4 mT
Dimensions
Body Height 1mm
Compliance
RoHS Status ROHS3 Compliant
