TLE49644MXTMA1
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
Hall Effect Sensor 25mA Unipolar 3.3V/5V/9V/12V/15V/18V/24V 3-Pin SOT-23 T/R
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.704
≥1 USD $0.704
≥10 USD $0.53504
≥100 USD $0.46112
≥500 USD $0.444752
≥1000 USD $0.37884
≥3000 USD $0.329384
Inventory: 1191
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Body Height 1mm
Technical
Magnetic Field Range-Max 13.5 mT
Magnetic Field Range-Min 5.4 mT
Hysteresis 1.5 mT
Sensing Range 13.5mT Trip, 5.4mT Release
Housing PLASTIC
Test Condition 25°C
Current - Output (Max) 25mA
Polarization South Pole
Termination Type SOLDER
Output Type Open Drain
Body Breadth 1.3 mm
Body Length or Diameter 2.9mm
Current - Supply (Max) 2.5mA
Function Unipolar Switch
Voltage - Supply 3V~32V
Technology Hall Effect
Additional Feature AEC-Q100; REVERSE POLARITY PROTECTION
Terminal Finish Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Temperature Compensated
JESD-609 Code e3
Series Automotive, AEC-Q100
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -40°C~170°C TJ
Physical
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 26 Weeks
