TLE49643KXTSA1

Infineon Technologies
RoHS
RoHS RoHS compliant
Package TO-236-3, SC-59, SOT-23-3
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description Hall Effect Sensor 25mA Unipolar 3.3V/5V/9V/12V/15V/18V/24V Automotive 3-Pin SC-59 T/R
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7744
≥1 USD $0.7744
≥10 USD $0.5896
≥100 USD $0.507936
≥500 USD $0.489808
≥1000 USD $0.417208
≥3000 USD $0.362806
Inventory: 1133
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Technical

Magnetic Field Range-Max 16.6 mT
Magnetic Field Range-Min 6.1 mT
Output Range 0-25mA
Sensing Range 12.5mT Trip, 9.5mT Release
Test Condition 25°C
Output Polarity INVERTING
Halogen Free Halogen Free
Max Supply Current 2.5mA
Output Current 25mA
Polarization North Pole, South Pole
Termination Type SOLDER
Output Type Open Drain
Body Breadth 1.6 mm
Current - Supply (Max) 1.6mA
Function Unipolar Switch
Voltage - Supply 3V~32V
Technology Hall Effect
Subcategory Other Sensors/Transducers
Terminal Finish Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Temperature Compensated
JESD-609 Code e3
Series Automotive, AEC-Q100
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -40°C~170°C TJ

Physical

Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Through Hole
Mount Surface Mount

Supply Chain

Factory Lead Time 16 Weeks
