TLE49641MXTSA1

Infineon Technologies
RoHS
RoHS RoHS compliant
Package TO-236-3, SC-59, SOT-23-3
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description Hall Effect Sensor 25mA Unipolar 3.3V/5V/9V/12V/15V/18V/24V Automotive 3-Pin SOT-23 T/R
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.704
≥1 USD $0.704
≥10 USD $0.53504
≥100 USD $0.46112
≥500 USD $0.444752
≥1000 USD $0.37884
≥3000 USD $0.329384
Inventory: 20055
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 26 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3

Technical

Operating Temperature -40°C~170°C TJ
Packaging Tape & Reel (TR)
Published 2010
Series Automotive, AEC-Q100
JESD-609 Code e3
Feature Temperature Compensated
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin (Sn)
Subcategory Other Sensors/Transducers
Technology Hall Effect
Voltage - Supply 3V~32V
Function Unipolar Switch
Current - Supply (Max) 2.5mA
Body Length or Diameter 2.9mm
Output Type Open Drain
Max Output Current 25mA
Operating Supply Voltage 32V
Polarity South Pole
Termination Type SOLDER
Polarization South Pole
Output Current 25mA
Max Supply Current 2.5mA
Sensing Method Hall Effect
Test Condition 25°C
Housing PLASTIC
Sensing Range 23.5mT Trip, 8.4mT Release
Hysteresis 5.5 mT
Output Range 0-25mA
Magnetic Field Range-Min 8.4 mT

Dimensions

Body Height 1mm

Compliance

RoHS Status ROHS3 Compliant
