TLE49632MXTMA1
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH LATCH SOT23-3
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.149036
≥1 USD $0.149036
≥200 USD $0.057675
≥500 USD $0.055648
≥1000 USD $0.054647
Inventory: 1167
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Body Height 1mm
Technical
Magnetic Field Range-Max 7.3 mT
Magnetic Field Range-Min -7.3 mT
Hysteresis 10 mT
Sensing Range 7.3mT Trip, -7.3mT Release
Housing PLASTIC
Test Condition 25°C
Current - Output (Max) 5mA
Polarization South Pole
Termination Type SOLDER
Output Type Open Drain
Body Breadth 1.3 mm
Body Length or Diameter 2.9mm
Current - Supply (Max) 2.5mA
Function Latch
Voltage - Supply 3V~5.5V
Technology Hall Effect
Terminal Finish Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Temperature Compensated
JESD-609 Code e3
Series Automotive, AEC-Q100
Published 2015
Packaging Tape & Reel (TR)
Operating Temperature -40°C~170°C TJ
Physical
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
