TLE49613MXTSA1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
Hall Effect Sensor 25mA Bipolar Latch 3.3V/5V/9V/12V/15V/18V/24V 3-Pin SOT-23 T/R
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.704
≥1 USD $0.704
≥10 USD $0.53504
≥100 USD $0.46112
≥500 USD $0.444752
≥1000 USD $0.37884
≥3000 USD $0.329384
Inventory: 1153
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 26 Weeks
Physical
Surface Mount YES
Mounting Feature SURFACE MOUNT
Technical
Packaging Tape & Reel (TR)
Published 2010
Series Automotive, AEC-Q100
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin (Sn)
Additional Feature REVERSE POLARITY PROTECTION, OPEN DRAIN OUTPUT
Subcategory Other Sensors/Transducers
Output OPEN-DRAIN
Body Length or Diameter 2.9mm
Body Breadth 1.3 mm
Output Type CURRENT OUTPUT
Supply Voltage-Max (Vsup) 32V
Power Supplies 3/32V
Supply Voltage-Min (Vsup) 3V
Termination Type SOLDER
Output Current-Max 25mA
Output Polarity INVERTING
Sensors/Transducers Type MAGNETIC FIELD SENSOR,HALL EFFECT
Housing PLASTIC
Hysteresis 15 mT
Output Range 0-25mA
Magnetic Field Range-Min -10.4 mT
Magnetic Field Range-Max 10.4 mT
Operating Current-Max 2.5mA
Input Mode BIPOLAR(LATCHED)
Dimensions
Body Height 1mm
Compliance
RoHS Status ROHS3 Compliant
