TLE4905GT image
Favorite
TLE4905GT image
Favorite
RoHS
RoHS RoHS compliant
Package TO-243AA
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description MAGNETIC SWITCH UNIPOLAR SOT89-3
PDF
/
Inventory: 8690
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Technical

Sensing Range 18mT Trip, 5mT Release
Test Condition 25°C
Sensing Method Hall Effect
Max Supply Current 5mA
Output Current 100mA
Current - Output (Max) 100mA
Polarization South Pole
Min Supply Voltage 4V
Max Supply Voltage 24V
Polarity South Pole
Max Output Current 100mA
Output Type Open Collector
Current - Supply (Max) 5mA
Function Unipolar Switch
Voltage - Supply 4V~18V
Technology Hall Effect
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Feature Temperature Compensated
Series TLE
Published 2000
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ

Physical

Supplier Device Package SOT-89-3
Number of Pins 4
Package / Case TO-243AA
Mounting Type Surface Mount
Mount Surface Mount
