TLE4905GNTSA1
RoHS
/
Package TO-243AA
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR SOT89-3
PDF
/
Inventory: 8577
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Width 2.5mm
Length 4.5mm
Height Seated (Max) 1.6mm
Technical
Sensing Range 18mT Trip, 5mT Release
Test Condition 25°C
Current - Output (Max) 100mA
Polarization South Pole
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 4V
Supply Voltage-Max (Vsup) 24V
Output Type Open Collector
Qualification Status Not Qualified
Current - Supply (Max) 5mA
Function Unipolar Switch
JESD-30 Code R-PSSO-F3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 1.5mm
Supply Voltage 12V
Peak Reflow Temperature (Cel) 260
Terminal Form FLAT
Terminal Position SINGLE
Voltage - Supply 4V~18V
Technology Hall Effect
HTS Code 8542.39.00.01
Terminal Finish TIN LEAD
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Temperature Compensated
JESD-609 Code e0
Series TLE
Published 2000
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Surface Mount YES
Package / Case TO-243AA
Mounting Type Surface Mount
