AH3777-P-A
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP, Formed Leads
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH LATCH 3SIP
PDF
/
Buying Options
Total Price: USD $0.31
Unit Price: USD $0.306418
≥1 USD $0.306418
≥200 USD $0.118581
≥500 USD $0.114419
≥1000 USD $0.112358
Inventory: 9582
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mounting Type Through Hole
Package / Case 3-SIP, Formed Leads
Surface Mount NO
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Box (TB)
Published 2015
JESD-609 Code e3
Feature Temperature Compensated
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Matte Tin (Sn)
Technology Hall Effect
Voltage - Supply 3V~28V
Function Latch
Current - Supply (Max) 4mA
Body Length or Diameter 4.1mm
Body Breadth 2.235 mm
Output Type Open Drain
Max Output Current 60mA
Polarity South Pole
Termination Type SOLDER
Polarization South Pole
Max Supply Current 4mA
Sensing Method Hall Effect
Test Condition -40°C ~ 125°C
Sensing Range 17mT Trip, -17mT Release
Hysteresis 28 mT
Output Range 30-55mA
Magnetic Field Range-Min -17 mT
Magnetic Field Range-Max 17 mT
Compliance
RoHS Status ROHS3 Compliant
