AH3776-SA-7
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH LATCH SOT23-3
PDF
/
Buying Options
Total Price: USD $0.66
Unit Price: USD $0.66
≥1 USD $0.66
≥10 USD $0.50688
≥100 USD $0.43648
≥500 USD $0.420992
≥1000 USD $0.3586
≥3000 USD $0.311784
Inventory: 1132
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 2015
JESD-609 Code e3
Feature Temperature Compensated
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Technology Hall Effect
Voltage - Supply 3V~28V
Function Latch
Current - Supply (Max) 4mA
Body Length or Diameter 2.9mm
Body Breadth 1.3 mm
Output Type Open Drain
Max Output Current 60mA
Polarity South Pole
Termination Type SOLDER
Polarization South Pole
Output Current 60mA
Max Supply Current 4mA
Sensing Method Hall Effect
Test Condition -40°C ~ 125°C
Sensing Range 14mT Trip, -14mT Release
Hysteresis 22 mT
Output Range 30-55mA
Magnetic Field Range-Min -14 mT
Magnetic Field Range-Max 14 mT
Dimensions
Body Height 1.025mm
Compliance
RoHS Status ROHS3 Compliant
