AH3774-P-B image
Favorite
AH3774-P-B image
Favorite
RoHS
RoHS RoHS compliant
Package 3-SIP Module
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description MAGNETIC SWITCH LATCH 3SIP
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.6688
≥1 USD $0.6688
≥10 USD $0.50952
≥100 USD $0.438944
≥500 USD $0.42328
≥1000 USD $0.360624
≥3000 USD $0.313562
Inventory: 26186
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Magnetic Field Range-Max 6 mT
Magnetic Field Range-Min -6 mT
Output Range 30-55mA
Hysteresis 8 mT
Sensing Range 6mT Trip, -6mT Release
Test Condition -40°C ~ 125°C
Sensing Method Hall Effect
Max Supply Current 4mA
Polarization South Pole
Termination Type SOLDER
Polarity South Pole
Max Output Current 60mA
Output Type Open Drain
Body Breadth 1.5 mm
Body Length or Diameter 4.1mm
Current - Supply (Max) 4mA
Function Latch
Voltage - Supply 3V~28V
Technology Hall Effect
Terminal Finish Matte Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Temperature Compensated
JESD-609 Code e3
Published 2015
Packaging Bulk
Operating Temperature -40°C~125°C TA

Physical

Surface Mount NO
Package / Case 3-SIP Module
Mounting Type Through Hole

Supply Chain

Factory Lead Time 19 Weeks
