AH3761-PG-B
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH LATCH 3SIP
PDF
/
Buying Options
Total Price: USD $11.88
Unit Price: USD $11.88165
≥1 USD $11.88165
≥10 USD $9.7489
≥100 USD $9.44395
≥500 USD $9.13995
≥1000 USD $8.835
Inventory: 3237
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Body Height 4.55mm
Technical
Magnetic Field Range-Max 6 mT
Magnetic Field Range-Min -6 mT
Output Range 50-90mA
Hysteresis 6 mT
Sensing Range 6mT Trip, -6mT Release
Test Condition 25°C
Sensing Method Hall Effect
Max Supply Current 6mA
Output Current 90mA
Polarization South Pole
Operating Supply Current 4mA
Polarity South Pole
Operating Supply Voltage 24V
Max Output Current 100mA
Output Type Open Drain
Output Voltage 30V
Body Breadth 1.5 mm
Body Length or Diameter 4.1mm
Function Latch
Voltage - Supply 3V~28V
Technology Hall Effect
Max Power Dissipation 550mW
Additional Feature SEATED HEIGHT-CALCULATED
Type Hall Effect Latch
Termination Through Hole
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Temperature Compensated
JESD-609 Code e3
Published 2011
Packaging Bulk
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 3
Package / Case 3-SSIP
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 12 Weeks
