AH1808-P-B
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH OMNIPOLAR 3SIP
PDF
/
Buying Options
Total Price: USD $0.47
Unit Price: USD $0.4664
≥1 USD $0.4664
≥10 USD $0.35816
≥100 USD $0.308704
≥500 USD $0.297616
≥1000 USD $0.253528
≥3000 USD $0.220422
Inventory: 124963
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mounting Type Through Hole
Package / Case 3-SSIP
Surface Mount NO
Technical
Operating Temperature -40°C~85°C TA
Packaging Bulk
Published 2015
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Matte Tin (Sn)
Technology Hall Effect
Voltage - Supply 2.5V~5.5V
Function Omnipolar Switch
Current - Supply (Max) 16μA
Body Length or Diameter 4.1mm
Body Breadth 1.5 mm
Output Type Open Drain
Max Output Current 2.5mA
Termination Type SOLDER
Polarization North Pole, South Pole
Max Supply Current 16μA
Sensing Method Hall Effect
Test Condition -40°C ~ 85°C
Sensing Range ±6mT Trip, ±5mT Release
Hysteresis 1 mT
Magnetic Field Range-Min 1 mT
Magnetic Field Range-Max 6 mT
Compliance
RoHS Status ROHS3 Compliant
