APS12230LLHALX
RoHS
RoHS compliant
RoHS compliantPackage SOT-23W
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH LATCH
PDF
/
Inventory: 1402
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Body Height 1mm
Technical
Output Interface Type 3-WIRE INTERFACE
Hysteresis 30 mT
Sensing Range 18mT Trip, -18mT Release
Test Condition -40°C ~ 150°C
Current - Output (Max) 60mA
Polarization North Pole, South Pole
Termination Type SOLDER
Output Type Open Drain
Body Breadth 1.91 mm
Body Length or Diameter 2.98mm
Current - Supply (Max) 3mA
Function Latch
Voltage - Supply 2.8V~24V
Technology Hall Effect
Additional Feature AEC-Q100; ISO 26262; SHORT CIRCUIT PROTECTION
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TA
Physical
Surface Mount YES
Package / Case SOT-23W
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
