APS11205LUAA
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
5V AUTO GRADE HALL EFFECT LATCH
PDF
/
Buying Options
Total Price: USD $0.76
Unit Price: USD $0.7568
≥1 USD $0.7568
≥10 USD $0.57728
≥100 USD $0.497728
≥500 USD $0.479952
≥1000 USD $0.408848
≥3000 USD $0.35552
Inventory: 12021
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 1.52mm
Length 4.09mm
Height Seated (Max) 4.12mm
Technical
Sensing Range 3.5mT Trip, 2.5mT Release
Test Condition -40°C ~ 150°C
Current - Output (Max) 5mA
Polarization South Pole
Analog IC - Other Type ANALOG CIRCUIT
Number of Channels 1
Supply Voltage-Min (Vsup) 2.8V
Supply Voltage-Max (Vsup) 5.5V
Output Type Open Drain
Current - Supply (Max) 4mA
Function Unipolar Switch
JESD-30 Code X-XSIP-T3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Voltage - Supply 2.8V~5.5V
Technology Hall Effect
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Temperature Compensated
JESD-609 Code e3
Series Automotive, AEC-Q100
Packaging Bulk
Operating Temperature -40°C~150°C
Physical
Surface Mount NO
Package / Case 3-SSIP
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
