APS11200LLHALT
RoHS
RoHS compliant
RoHS compliantPackage SOT-23W
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
Tape & Reel (TR) Automotive AEC-Q100 3-WIRE INTERFACE Hall Effect Digital Unipolar Switch 1.91mm 60mA 2.8V~24V -40C~150C TA
PDF
/
Buying Options
Total Price: USD $1.08
Unit Price: USD $1.0824
≥1 USD $1.0824
≥10 USD $0.81312
≥100 USD $0.650496
≥500 USD $0.596376
≥1000 USD $0.501512
≥3000 USD $0.447286
Inventory: 1393
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case SOT-23W
Surface Mount YES
Technical
Operating Temperature -40°C~150°C TA
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Additional Feature AEC-Q100; ISO 26262; SHORT CIRCUIT PROTETCION
Technology Hall Effect
Voltage - Supply 2.8V~24V
Function Unipolar Switch
Current - Supply (Max) 3mA
Body Length or Diameter 2.98mm
Body Breadth 1.91 mm
Output Type Open Drain
Termination Type SOLDER
Polarization North Pole, South Pole
Current - Output (Max) 60mA
Test Condition -40°C ~ 150°C
Sensing Range ±5mT Trip, ±0.5mT Release
Hysteresis 1 mT
Magnetic Field Range-Min 0.5 mT
Output Interface Type 3-WIRE INTERFACE
Magnetic Field Range-Max 5 mT
Dimensions
Body Height 1mm
Compliance
RoHS Status ROHS3 Compliant
