A3425LL-T
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH BIPOLAR 8SOIC
PDF
/
Inventory: 5300
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Sensing Range 3mT Trip, -3mT Release
Test Condition -40°C ~ 150°C
Output Current 70mA
Polarization South Pole
Operating Supply Current 6mA
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 3.3V
Supply Voltage-Max (Vsup) 18V
Max Output Current 20mA
Output Type Open Drain
Qualification Status Not Qualified
Current - Supply (Max) 6mA
Function Bipolar Switch
JESD-30 Code R-PDSO-G8
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Supply Voltage 12V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3.3V~18V
Technology Hall Effect
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2009
Packaging Bulk
Operating Temperature -40°C~150°C TA
Physical
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
