A3295KLHLT-T
RoHS
RoHS compliant
RoHS compliantPackage SOT-23W
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
Hall Effect Sensor 25mA Unipolar 5V/9V/12V/15V/18V 3-Pin SOT-23W T/R
PDF
/
Buying Options
Total Price: USD $1.1
Unit Price: USD $1.1
≥1 USD $1.1
≥10 USD $0.82632
≥100 USD $0.661408
≥500 USD $0.606144
≥1000 USD $0.509731
≥3000 USD $0.454626
Inventory: 12004
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Body Height 1mm
Technical
Magnetic Field Range-Max 7.5 mT
Magnetic Field Range-Min 0.5 mT
Hysteresis 7 mT
Sensing Range 7.5mT Trip, 0.5mT Release
Test Condition -40°C ~ 125°C
Sensing Method Hall Effect
Max Supply Current 8mA
Output Current 25mA
Polarization South Pole
Operating Supply Current 8mA
Polarity South Pole
Max Output Current 25mA
Output Type Open Drain
Body Breadth 1.91 mm
Body Length or Diameter 2.98mm
Function Unipolar Switch
Voltage - Supply 3V~24V
Technology Hall Effect
Terminal Finish Matte Tin (Sn)
Type Unipolar Switch
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 3
Package / Case SOT-23W
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
