A3282LUA
RoHS
/
Package 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH LATCH 3SIP
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.64385
≥100 USD $2.5612
≥500 USD $2.47855
≥1000 USD $2.3959
Inventory: 10206
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 1.52mm
Length 4.105mm
Height Seated (Max) 5.26mm
Technical
Sensing Range 15mT Trip, -15mT Release
Test Condition -40°C ~ 150°C
Current - Output (Max) 60mA
Polarization South Pole
Operating Supply Current 3.5mA
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 3.6V
Supply Voltage-Max (Vsup) 24V
Max Output Current 25mA
Output Type Open Drain
Qualification Status Not Qualified
Function Latch
JESD-30 Code R-PSIP-T3
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Peak Reflow Temperature (Cel) 240
Terminal Position SINGLE
Voltage - Supply 3.6V~24V
Technology Hall Effect
HTS Code 8542.39.00.01
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2010
Packaging Bulk
Operating Temperature -40°C~150°C TA
Physical
Surface Mount NO
Package / Case 3-SSIP
Mounting Type Through Hole
