A3260LUA
RoHS
/
Package 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH BIPOLAR 3SIP
PDF
/
Inventory: 3762
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 1.52mm
Length 4.105mm
Height Seated (Max) 5.26mm
Technical
Sensing Range 4mT Trip, -4mT Release
Test Condition -40°C ~ 150°C
Polarization South Pole
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 24V
Max Output Current 8mA
Output Type Open Collector
Qualification Status Not Qualified
Function Bipolar Switch
JESD-30 Code R-PSIP-T3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Supply Voltage 12V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Voltage - Supply 3.5V~24V
Technology Hall Effect
HTS Code 8542.39.00.01
Additional Feature REVERSE BATTERY PROTECTION
Terminal Finish Matte Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2003
Packaging Bulk
Operating Temperature -40°C~150°C TA
Physical
Surface Mount NO
Package / Case 3-SSIP
Mounting Type Through Hole
