A3250ELT
RoHS
/
Package TO-243AA
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
Bulk Open Collector Hall Effect Programmable Trip Point Digital Unipolar Switch 4.5mm 20mA 4.2V~24V -40C~85C TA
PDF
/
Inventory: 8064
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-243AA
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Bulk
Published 2011
JESD-609 Code e0
Feature Programmable Trip Point
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish TIN LEAD
HTS Code 8542.39.00.01
Technology Hall Effect
Voltage - Supply 4.2V~24V
Terminal Position SINGLE
Terminal Form FLAT
Peak Reflow Temperature (Cel) 240
Supply Voltage 12V
Terminal Pitch 1.5mm
Time@Peak Reflow Temperature-Max (s) 30
JESD-30 Code R-PSSO-F3
Function Unipolar Switch
Current - Supply (Max) 7mA
Qualification Status Not Qualified
Output Type Open Collector
Supply Voltage-Max (Vsup) 24V
Supply Voltage-Min (Vsup) 4.2V
Analog IC - Other Type ANALOG CIRCUIT
Polarization South Pole
Current - Output (Max) 20mA
Sensing Range Programmable
Dimensions
Height Seated (Max) 1.6mm
Length 4.5mm
Width 2.445mm
Compliance
RoHS Status Non-RoHS Compliant
