A3242LUA-T
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR 3SIP
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 58
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 3-SSIP
Surface Mount NO
Technical
Operating Temperature -40°C~150°C TA
Packaging Bulk
Published 2006
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Type Unipolar Switch
Terminal Finish Matte Tin (Sn)
HTS Code 8542.39.00.01
Technology Hall Effect
Voltage - Supply 3.6V~24V
Terminal Position SINGLE
Peak Reflow Temperature (Cel) 260
Supply Voltage 12V
Terminal Pitch 1.27mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PSIP-T3
Function Unipolar Switch
Qualification Status Not Qualified
Output Type Open Drain
Supply Voltage-Max (Vsup) 24V
Supply Voltage-Min (Vsup) 3.6V
Operating Supply Current 3.5mA
Polarization South Pole
Current - Output (Max) 60mA
Test Condition -40°C ~ 150°C
Sensing Range 20mT Trip, 11mT Release
Dimensions
Height Seated (Max) 5.26mm
Length 4.09mm
Width 1.52mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
