A3240LUA-T
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR 3SIP
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.05505
≥1 USD $8.05505
≥10 USD $6.60915
≥100 USD $6.403
≥500 USD $6.1959
≥1000 USD $5.98975
Inventory: 247
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 1.52mm
Length 4.09mm
Height Seated (Max) 5.26mm
Technical
Sensing Range 5mT Trip, 5mT Release
Test Condition -40°C ~ 150°C
Polarization South Pole
Operating Supply Current 6mA
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 4.2V
Supply Voltage-Max (Vsup) 24V
Max Output Current 25mA
Output Type Open Collector
Qualification Status Not Qualified
Current - Supply (Max) 6mA
Function Unipolar Switch
JESD-30 Code R-PSIP-T3
Time@Peak Reflow Temperature-Max (s) 40
Current Rating 4mA
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Supply Voltage 12V
Peak Reflow Temperature (Cel) 260
Terminal Position SINGLE
Voltage - Supply 4.2V~24V
Technology Hall Effect
HTS Code 8542.39.00.01
Additional Feature OPERATION FROM UNREGULATED SUPPLY; REVERSE BATTERY PROTECTION
Terminal Finish Matte Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2003
Packaging Bulk
Operating Temperature -40°C~150°C TA
Physical
Surface Mount NO
Package / Case 3-SSIP
Mounting Type Through Hole
