A3240LUA
RoHS
/
Package 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR 3SIP
PDF
/
Inventory: 7647
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 1.52mm
Length 4.105mm
Height Seated (Max) 5.26mm
Technical
Sensing Range 5mT Trip, 5mT Release
Test Condition -40°C ~ 150°C
Output Current 25mA
Polarization South Pole
Operating Supply Current 6mA
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 24V
Max Output Current 25mA
Output Type Open Collector
Qualification Status Not Qualified
Current - Supply (Max) 6mA
Function Unipolar Switch
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 4mA
Terminal Pitch 1.27mm
Supply Voltage 12V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Voltage - Supply 4.2V~24V
Technology Hall Effect
Additional Feature REVERSE BATTERY PROTECTION
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2009
Packaging Bulk
Operating Temperature -40°C~150°C TA
Physical
Number of Pins 3
Package / Case 3-SSIP
Mounting Type Through Hole
Mount Through Hole
