A3240LLHLT-T
RoHS
RoHS compliant
RoHS compliantPackage SOT-23W
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR SOT23W
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5529
≥1 USD $0.5529
≥10 USD $0.4541
≥100 USD $0.43985
≥500 USD $0.4256
≥1000 USD $0.41135
Inventory: 5273
Minimum: 1
-
+
Technical Details
Technical
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Matte Tin (Sn)
Additional Feature OPERATION FROM UNREGULATED SUPPLY; REVERSE BATTERY PROTECTION
Technology Hall Effect
Voltage - Supply 4.2V~24V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 12V
Terminal Pitch 0.95mm
Reach Compliance Code unknown
Current Rating 4mA
Time@Peak Reflow Temperature-Max (s) 40
Function Unipolar Switch
Current - Supply (Max) 6mA
Qualification Status Not Qualified
Output Type Open Collector
Max Output Current 25mA
Supply Voltage-Max (Vsup) 24V
Supply Voltage-Min (Vsup) 4.2V
Analog IC - Other Type ANALOG CIRCUIT
Operating Supply Current 6mA
Polarization South Pole
Output Current 25mA
Test Condition -40°C ~ 150°C
Part Status Obsolete
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TA
Sensing Range 5mT Trip, 5mT Release
Physical
Number of Pins 3
Package / Case SOT-23W
Mounting Type Surface Mount
Mount Surface Mount
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 1.91mm
Length 2.98mm
