A3214LLHLT
RoHS
/
Package SOT-23W
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH OMNIPOLAR SOT23W
PDF
/
Inventory: 7936
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 1.975mm
Technical
Sensing Range ±7mT Trip, ±1mT Release
Test Condition -40°C ~ 150°C
Polarization North Pole, South Pole
Operating Supply Current 2mA
Supply Voltage-Min (Vsup) 2.4V
Supply Voltage-Max (Vsup) 5.5V
Max Output Current 1mA
Output Type Open Drain
Qualification Status Not Qualified
Current - Supply (Max) 2mA
Function Omnipolar Switch
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.95mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.4V~5.5V
Technology Hall Effect
Terminal Finish TIN LEAD
Type Omnipolar Switch
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2003
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TA
Physical
Number of Pins 3
Surface Mount YES
Package / Case SOT-23W
Mounting Type Surface Mount
