A3213LUA-T
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH OMNIPOLAR 3SIP
PDF
/
Buying Options
Total Price: USD $1.2
Unit Price: USD $1.1968
≥1 USD $1.1968
≥10 USD $0.89584
≥100 USD $0.716672
≥500 USD $0.657008
≥1000 USD $0.552482
≥3000 USD $0.492747
Inventory: 1646
Minimum: 1
-
+
Technical Details
Technical
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.4V
Operating Supply Current 2mA
Polarization North Pole, South Pole
Output Current 1mA
Test Condition -40°C ~ 150°C
Sensing Range ±7mT Trip, ±1mT Release
Operating Supply Voltage 3V
Max Output Current 1mA
Output Type Open Drain
Current - Supply (Max) 2mA
Function Omnipolar Switch
Terminal Pitch 1.27mm
Supply Voltage 3V
Terminal Position SINGLE
Voltage - Supply 2.4V~5.5V
Technology Hall Effect
Terminal Finish Matte Tin (Sn)
Type Omnipolar Switch
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2009
Packaging Bulk
Operating Temperature -40°C~150°C TA
Dimensions
Length 4.09mm
Width 1.52mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 3
Package / Case 3-SSIP
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
