A3212LUA-T
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
Hall Effect Sensor 1mA Latch 2.75V 3-Pin Ultra Mini SIP Bulk
PDF
/
Buying Options
Total Price: USD $1.31
Unit Price: USD $1.3112
≥1 USD $1.3112
≥10 USD $0.98384
≥100 USD $0.787072
≥500 USD $0.721512
≥1000 USD $0.606742
≥3000 USD $0.541147
Inventory: 1680
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 1.52mm
Length 4.09mm
Height Seated (Max) 5.26mm
Technical
Sensing Range ±6.5mT Trip, ±1mT Release
Test Condition -40°C ~ 150°C
Max Supply Current 1μA
Output Current 1mA
Polarization North Pole, South Pole
Operating Supply Current 2mA
Supply Voltage-Min (Vsup) 2.5V
Operating Supply Voltage 2.75V
Max Output Current 1mA
Output Type Open Drain
Qualification Status Not Qualified
Function Omnipolar Switch
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 2.75V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Voltage - Supply 2.5V~3.5V
Technology Hall Effect
Terminal Finish Matte Tin (Sn)
Type Omnipolar Switch
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2012
Packaging Bulk
Operating Temperature -40°C~150°C TA
Physical
Number of Pins 3
Package / Case 3-SSIP
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
