A1425LK-T
RoHS
RoHS compliant
RoHS compliantPackage 4-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
Hall Effect Sensor 25mA Monolithic 5V/9V/12V/15V/18V/24V 4-Pin SIP Bulk
PDF
/
Buying Options
Total Price: USD $3.57
Unit Price: USD $3.5728
≥1 USD $3.5728
≥10 USD $2.6796
≥100 USD $2.381984
≥500 USD $2.262832
≥1000 USD $2.203344
≥3000 USD $1.846029
Inventory: 138
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 1.55mm
Length 5.21mm
Height Seated (Max) 5.67mm
Technical
Sensing Range 1.1mT Trip, -1.1mT Release
Test Condition -40°C ~ 150°C
Max Supply Current 7mA
Output Current 25mA
Polarization South Pole
Operating Supply Current 7mA
Analog IC - Other Type ANALOG CIRCUIT
Supply Voltage-Min (Vsup) 4V
Supply Voltage-Max (Vsup) 26.5V
Max Output Current 25mA
Output Type Open Drain
Qualification Status Not Qualified
Function Special Purpose
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 12V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Voltage - Supply 4V~26.5V
Technology Hall Effect
Additional Feature REVERSE BATTERY PROTECTION
Terminal Finish Matte Tin (Sn)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Temperature Compensated
JESD-609 Code e3
Series Automotive, AEC-Q100
Published 2009
Packaging Bulk
Operating Temperature -40°C~150°C TA
Physical
Number of Pins 4
Package / Case 4-SSIP
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
