A1422LK
RoHS
/
Package 4-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH SPEC PURP 4SIP
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.64385
≥100 USD $2.5612
≥500 USD $2.47855
≥1000 USD $2.3959
Inventory: 5402
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 4-SSIP
Surface Mount NO
Technical
Operating Temperature -40°C~150°C TA
Packaging Bulk
Published 2012
Series Automotive, AEC-Q100
JESD-609 Code e0
Feature Temperature Compensated
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Terminal Finish TIN LEAD
HTS Code 8542.39.00.01
Technology Hall Effect
Voltage - Supply 4V~26.5V
Terminal Position SINGLE
Peak Reflow Temperature (Cel) 240
Supply Voltage 12V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PSIP-T4
Function Special Purpose
Current - Supply (Max) 7mA
Qualification Status Not Qualified
Output Type Open Drain
Max Output Current 25mA
Supply Voltage-Max (Vsup) 26.5V
Supply Voltage-Min (Vsup) 4V
Analog IC - Other Type MOTION SENSOR
Operating Supply Current 7mA
Polarization South Pole
Test Condition -40°C ~ 150°C
Sensing Range 3.5mT Trip, -3.5mT Release
Dimensions
Height Seated (Max) 5.67mm
Length 5.22mm
Width 1.55mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
