A1242LUA-I2-T
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
Bulk Open Collector Hall Effect REVERSE BATTERY PROTECTION Digital Latch 1.52mm 5mA 3.5V~24V -40C~150C TA
PDF
/
Inventory: 3211
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Packaging Bulk
Operating Temperature -40°C~150°C TA
Magnetic Field Range-Max 8 mT
Magnetic Field Range-Min -8 mT
Hysteresis 6.4 mT
Sensing Range 8mT Trip, -8mT Release
Test Condition -40°C ~ 150°C
Polarization South Pole
Operating Supply Current 6.9mA
Output Type Open Collector
Body Breadth 1.52 mm
Body Length or Diameter 4.09mm
Current - Supply (Max) 5mA
Function Latch
Reach Compliance Code unknown
Voltage - Supply 3.5V~24V
Technology Hall Effect
Subcategory Other Sensors
Additional Feature REVERSE BATTERY PROTECTION
Terminal Finish Matte Tin (Sn)
Type Unipolar Switch
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2009
Physical
Number of Pins 3
Surface Mount NO
Package / Case 3-SSIP
Mounting Type Through Hole
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Body Height 5.2mm
