A1212EUA-T
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH LATCH 3SIP
PDF
/
Buying Options
Total Price: USD $19.15
Unit Price: USD $19.15485
≥1 USD $19.15485
≥10 USD $15.7168
≥100 USD $15.22565
≥500 USD $14.7345
≥1000 USD $14.24335
Inventory: 12004
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 3-SSIP
Number of Pins 3
Technical
Operating Temperature -40°C~85°C TA
Packaging Bulk
Published 2009
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Matte Tin (Sn)
Additional Feature BICMOS COMPATIBLE, REVERSE BATTERY PROTECTION
Subcategory Other Sensors
Technology Hall Effect
Voltage - Supply 3.8V~24V
Function Latch
Current - Supply (Max) 7.5mA
Body Length or Diameter 4.105mm
Body Breadth 1.52 mm
Output Type Open Drain
Max Output Current 25mA
Termination Type SOLDER
Operating Supply Current 7.5mA
Polarization South Pole
Output Current 25mA
Output Polarity NON-INVERTING
Test Condition -40°C ~ 85°C
Sensing Range 17mT Trip, -17mT Release
Hysteresis 22.5 mT
Output Range 400mV
Magnetic Field Range-Min -17.5 mT
Magnetic Field Range-Max 17.5 mT
Input Mode UNIPOLAR
Dimensions
Body Height 5.2mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
