A1203LLHLT-T
RoHS
RoHS compliant
RoHS compliantPackage SOT-23W
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
ALLEGRO MICROSYSTEMS A1203LLHLT-T Hall Effect Sensor, Bipolar, 25 mA, SOT-23, 3 Pins, 3.8 V, 24 V
PDF
/
Buying Options
Total Price: USD $1.71
Unit Price: USD $1.7072
≥1 USD $1.7072
≥10 USD $1.32
≥100 USD $1.1
≥500 USD $1.07536
≥1000 USD $0.97768
≥3000 USD $0.855466
Inventory: 1260
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 1.91mm
Length 2.98mm
Technical
Sensing Range 9.5mT Trip, -9.5mT Release
Test Condition -40°C ~ 150°C
Screening Level AEC-Q100
Max Supply Current 7.5mA
Output Current 25mA
Polarization North Pole, South Pole
Operating Supply Current 7.5mA
Supply Voltage-Max (Vsup) 24V
Max Output Current 25mA
Output Type Open Drain
Qualification Status Not Qualified
Function Latch
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.95mm
Supply Voltage 12V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3.8V~24V
Technology Hall Effect
Terminal Finish Matte Tin (Sn)
Type Bipolar Switch
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TA
Physical
Number of Pins 3
Package / Case SOT-23W
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
