A1202ELHLT-T
RoHS
RoHS compliant
RoHS compliantPackage SOT-23W
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH LATCH SOT23W
PDF
/
Inventory: 6803
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case SOT-23W
Surface Mount YES
Number of Pins 3
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2012
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Type Bipolar Switch
Terminal Finish Matte Tin (Sn)
Technology Hall Effect
Voltage - Supply 3.8V~24V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 12V
Terminal Pitch 0.95mm
Time@Peak Reflow Temperature-Max (s) 40
Function Latch
Current - Supply (Max) 7.5mA
Qualification Status Not Qualified
Output Type Open Drain
Max Output Current 25mA
Supply Voltage-Max (Vsup) 24V
Operating Supply Current 7.5mA
Polarization North Pole, South Pole
Test Condition -40°C ~ 85°C
Sensing Range 7.5mT Trip, -7.5mT Release
Dimensions
Width 1.975mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
