A1201LLHLT-T
RoHS
RoHS compliant
RoHS compliantPackage SOT-23W
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH LATCH SOT23W
PDF
/
Buying Options
Total Price: USD $1.61
Unit Price: USD $1.6112
≥1 USD $1.6112
≥10 USD $1.3224
≥100 USD $1.2806
≥500 USD $1.23975
≥1000 USD $1.19795
Inventory: 31
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23W
Number of Pins 3
Technical
Operating Temperature -40°C~150°C TA
Packaging Tape & Reel (TR)
Published 2006
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Matte Tin (Sn)
Additional Feature REVERSE BATTERY PROTECTION
Technology Hall Effect
Voltage - Supply 3.8V~24V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 12V
Terminal Pitch 0.95mm
Time@Peak Reflow Temperature-Max (s) 40
Function Latch
Current - Supply (Max) 7.5mA
Output Type Open Drain
Max Output Current 25mA
Supply Voltage-Max (Vsup) 24V
Analog IC - Other Type ANALOG CIRCUIT
Operating Supply Current 7.5mA
Polarization South Pole
Output Current 25mA
Test Condition -40°C ~ 150°C
Sensing Range 5mT Trip, -5mT Release
Dimensions
Length 2.98mm
Width 1.91mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
