A1180LLHLT
RoHS
/
Package SOT-23W
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR SOT23W
PDF
/
Inventory: 3874
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case SOT-23W
Surface Mount YES
Number of Pins 3
Technical
Operating Temperature -40°C~150°C TA
Packaging Tape & Reel (TR)
Published 2011
Series Automotive, AEC-Q100
JESD-609 Code e0
Feature Programmable Trip Point
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Type Unipolar Switch
Terminal Finish TIN LEAD
Technology Hall Effect
Voltage - Supply 3.5V~24V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Supply Voltage 5V
Terminal Pitch 0.95mm
Time@Peak Reflow Temperature-Max (s) 30
Function Unipolar Switch
Current - Supply (Max) 17mA
Qualification Status Not Qualified
Output Type Current Source
Supply Voltage-Max (Vsup) 24V
Operating Supply Current 5mA
Polarization South Pole
Sensing Range Programmable
Dimensions
Height Seated (Max) 1.17mm
Length 2.92mm
Width 1.975mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
