A1180ELHLT
RoHS
/
Package SOT-23W
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR SOT23W
PDF
/
Inventory: 9534
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 1.975mm
Length 2.92mm
Height Seated (Max) 1.17mm
Technical
Sensing Range Programmable
Polarization South Pole
Operating Supply Current 5mA
Supply Voltage-Min (Vsup) 3.5V
Supply Voltage-Max (Vsup) 24V
Output Type Current Source
Qualification Status Not Qualified
Current - Supply (Max) 17mA
Function Unipolar Switch
JESD-30 Code R-PDSO-G3
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.95mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3.5V~24V
Technology Hall Effect
HTS Code 8542.39.00.01
Terminal Finish TIN LEAD
Type Unipolar Switch
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Programmable Trip Point
JESD-609 Code e0
Series Automotive, AEC-Q100
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case SOT-23W
Mounting Type Surface Mount
