A1157LUA-T image
Favorite
A1157LUA-T image
Favorite
RoHS
RoHS RoHS compliant
Package 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description MAGNETIC SWITCH UNIPOLAR 3SIP
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4256
≥1 USD $1.4256
≥10 USD $1.06656
≥100 USD $0.853248
≥500 USD $0.782144
≥1000 USD $0.657712
≥3000 USD $0.586608
Inventory: 8021
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Technical

Magnetic Field Range-Max 11 mT
Magnetic Field Range-Min 4.5 mT
Sensing Range 8mT Trip, 1mT Release
Test Condition -40°C ~ 150°C
Polarization South Pole
Operating Supply Current 5mA
Output Type Current Source
Body Breadth 1.52 mm
Body Length or Diameter 4.09mm
Current - Supply (Max) 17mA
Function Unipolar Switch
Voltage - Supply 3V~24V
Technology Hall Effect
Subcategory Other Sensors/Transducers
Additional Feature REVERSE BATTERY PROTECTION
Terminal Finish Matte Tin (Sn)
Type Unipolar Switch
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2013
Packaging Bulk
Operating Temperature -40°C~150°C TA

Physical

Number of Pins 3
Package / Case 3-SSIP
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 8 Weeks
