A1150LUA-T
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR 3SIP
PDF
/
Buying Options
Total Price: USD $1.57
Unit Price: USD $1.5664
≥1 USD $1.5664
≥10 USD $1.17304
≥100 USD $0.938432
≥500 USD $0.860376
≥1000 USD $0.723483
≥3000 USD $0.645269
Inventory: 1469
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 3-SSIP
Number of Pins 3
Technical
Operating Temperature -40°C~150°C TA
Packaging Bulk
Published 2012
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Type Unipolar Switch
Terminal Finish Matte Tin (Sn)
Additional Feature REVERSE BATTERY PROTECTION
Subcategory Other Sensors/Transducers
Technology Hall Effect
Voltage - Supply 3V~24V
Function Unipolar Switch
Current - Supply (Max) 17mA
Body Length or Diameter 4.09mm
Body Breadth 1.52 mm
Output Type Current Source
Operating Supply Current 5mA
Polarization South Pole
Test Condition -40°C ~ 150°C
Sensing Range 11mT Trip, 4.5mT Release
Magnetic Field Range-Min 4.5 mT
Magnetic Field Range-Max 11 mT
Compliance
RoHS Status ROHS3 Compliant
