A1142EUA-T
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR 3SIP
PDF
/
Inventory: 1431
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 1.52mm
Length 4.105mm
Height Seated (Max) 5.26mm
Technical
Sensing Range 11mT Trip, 4.5mT Release
Test Condition -40°C ~ 85°C
Polarization South Pole
Operating Supply Current 6.9mA
Supply Voltage-Min (Vsup) 3.5V
Supply Voltage-Max (Vsup) 24V
Output Type Open Collector
Qualification Status Not Qualified
Function Unipolar Switch
JESD-30 Code R-PSIP-T3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Supply Voltage 12V
Peak Reflow Temperature (Cel) 260
Terminal Position SINGLE
Voltage - Supply 3.5V~24V
Technology Hall Effect
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
Type Unipolar Switch
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series Automotive, AEC-Q100
Published 2011
Packaging Bulk
Operating Temperature -40°C~85°C TA
Physical
Surface Mount NO
Package / Case 3-SSIP
Mounting Type Through Hole
