A1126LUA-T
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH OMNIPOLAR 3SIP
PDF
/
Buying Options
Total Price: USD $13.83
Unit Price: USD $13.82535
≥1 USD $13.82535
≥10 USD $11.34395
≥100 USD $10.9896
≥500 USD $10.6343
≥1000 USD $10.27995
Inventory: 9003
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 4.12mm
Technical
Input Mode UNIPOLAR
Magnetic Field Range-Max 5.5 mT
Magnetic Field Range-Min 0.5 mT
Ambient Temperature Range High 150°C
Sensing Range ±5.5mT Trip, ±5mT Release
Max Junction Temperature (Tj) 165°C
Test Condition -40°C ~ 150°C
Sensing Method Hall Effect
Output Polarity INVERTING
Max Supply Current 4mA
Output Current 60mA
Polarization North Pole, South Pole
Operating Supply Current 4mA
Output Type Open Drain
Body Breadth 1.52 mm
Body Length or Diameter 4.09mm
Function Omnipolar Switch
Voltage - Supply 3V~24V
Technology Hall Effect
Subcategory Other Sensors/Transducers
Terminal Finish Matte Tin (Sn)
Type Omnipolar Switch
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Automotive, AEC-Q100
Published 2006
Packaging Bulk
Operating Temperature -40°C~150°C TA
Physical
Manufacturer Package Identifier UA-3-Matrix
Number of Pins 3
Package / Case 3-SSIP
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
