A1126LLHLX-T
RoHS
RoHS compliant
RoHS compliantPackage SOT-23W
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH OMNIPOLAR SOT23W
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.410626
≥1 USD $0.410626
≥10 USD $0.403295
Inventory: 30091
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23W
Number of Pins 3
Technical
Operating Temperature -40°C~150°C TA
Packaging Tape & Reel (TR)
Published 2013
Series Automotive, AEC-Q100
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Type Omnipolar Switch
Terminal Finish Matte Tin (Sn)
Subcategory Other Sensors/Transducers
Technology Hall Effect
Voltage - Supply 3V~24V
Function Omnipolar Switch
Body Length or Diameter 2.98mm
Body Breadth 1.91 mm
Output Type Open Drain
Operating Supply Current 4mA
Polarization North Pole, South Pole
Output Current 60mA
Max Supply Current 4mA
Output Polarity INVERTING
Test Condition -40°C ~ 150°C
Sensing Range ±5.5mT Trip, ±5mT Release
Magnetic Field Range-Min 0.5 mT
Magnetic Field Range-Max 5.5 mT
Input Mode UNIPOLAR
Dimensions
Body Height 1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
