A1120LUA-T
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
ALLEGRO MICROSYSTEMS A1120LUA-T Hall Effect Switch, Unipolar Switch, Switch, 3 V, 24 V, SIP
PDF
/
Buying Options
Total Price: USD $0.73
Unit Price: USD $0.73224
≥1 USD $0.73224
≥10 USD $0.69079
≥100 USD $0.65169
≥500 USD $0.6148
≥1000 USD $0.58
Inventory: 3622
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 1.52mm
Length 4.09mm
Height 3.02mm
Technical
Magnetic Field Range-Max 5 mT
Magnetic Field Range-Min 0.5 mT
Hysteresis 1 mT
Sensing Range 5mT Trip, 0.5mT Release
Test Condition -40°C ~ 150°C
Bandwidth 800 kHz
Max Supply Current 4mA
Output Current 25mA
Polarization South Pole
Operating Supply Current 4mA
Max Output Current 25mA
Output Type Open Drain
Function Unipolar Switch
Voltage - Supply 3V~24V
Technology Hall Effect
Additional Feature AEC-Q100; SHORT CIRCUIT PROTECTION
Terminal Finish Matte Tin (Sn)
Type Unipolar Switch
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature High Temperature
JESD-609 Code e3
Series Automotive, AEC-Q100
Published 2010
Packaging Bulk
Operating Temperature -40°C~150°C TA
Physical
Number of Pins 3
Package / Case 3-SSIP
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
