A1102LUA-T
RoHS
RoHS compliant
RoHS compliantPackage 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH UNIPOLAR 3SIP
PDF
/
Buying Options
Total Price: USD $1.67
Unit Price: USD $1.672
≥1 USD $1.672
≥10 USD $1.50304
≥100 USD $1.417504
≥500 USD $1.2078
≥1000 USD $1.134109
≥3000 USD $0.992341
Inventory: 10349
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 3-SSIP
Number of Pins 3
Technical
Operating Temperature -40°C~150°C TA
Packaging Bulk
Published 2006
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Type Hall Effect Sensor, Unipolar Switch
Terminal Finish Matte Tin (Sn)
Additional Feature REVERSE BATTERY PROTECTION
Technology Hall Effect
Voltage - Supply 3.8V~24V
Terminal Position SINGLE
Supply Voltage 12V
Terminal Pitch 1.27mm
Function Unipolar Switch
Output Type Open Drain
Max Output Current 25mA
Operating Supply Voltage 5V
Supply Voltage-Max (Vsup) 24V
Operating Supply Current 7.5mA
Polarization South Pole
Output Current 20mA
Max Supply Current 7.5mA
Test Condition -40°C ~ 150°C
Sensing Range 24.5mT Trip, 6mT Release
Dimensions
Height Seated (Max) 5.26mm
Length 4.17mm
Width 1.57mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
