A1102LLHLT-T
RoHS
RoHS compliant
RoHS compliantPackage SOT-23W
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
ALLEGRO MICROSYSTEMS A1102LLHLT-T Hall Effect Switch, Unipolar Switch, Switch, 180 G, 125 G, 3.8 V, 24 V, SOT-23
PDF
/
Buying Options
Total Price: USD $1.99
Unit Price: USD $1.9888
≥1 USD $1.9888
≥10 USD $1.5312
≥100 USD $1.276
≥500 USD $1.247488
≥1000 USD $1.134144
≥3000 USD $0.992341
Inventory: 23304
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23W
Number of Pins 3
Technical
Operating Temperature -40°C~150°C TA
Packaging Tape & Reel (TR)
Published 2008
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination SMD/SMT
Type Unipolar Switch
Terminal Finish Matte Tin (Sn)
Additional Feature REVERSE BATTERY PROTECTION
Technology Hall Effect
Voltage - Supply 3.8V~24V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 12V
Terminal Pitch 0.95mm
Time@Peak Reflow Temperature-Max (s) 40
Function Unipolar Switch
Output Type Open Drain
Max Output Current 25mA
Supply Voltage-Max (Vsup) 24V
Operating Supply Current 7.5mA
Polarization South Pole
Output Current 20mA
Max Supply Current 7.5mA
Test Condition -40°C ~ 150°C
Sensing Range 24.5mT Trip, 6mT Release
Dimensions
Length 2.98mm
Width 1.91mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
