AK8772 image
Favorite
AK8772 image
Favorite
RoHS
RoHS RoHS compliant
Package 4-XFDFN Exposed Pad
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description MAGNETIC SWITCH LATCH 4DFN
PDF
/
Buying Options
Total Price: USD $5.53
Unit Price: USD $5.52995
≥1 USD $5.52995
≥10 USD $4.53815
≥100 USD $4.39565
≥500 USD $4.2541
≥1000 USD $4.11255
Inventory: 3439
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mounting Type Surface Mount
Package / Case 4-XFDFN Exposed Pad
Supplier Device Package 4-DFN (1.1x1.4)

Technical

Operating Temperature -30°C~85°C TA
Packaging Tape & Reel (TR)
Published 2012
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Technology Hall Effect
Voltage - Supply 1.6V~5.5V
Function Latch
Current - Supply (Max) 10mA
Output Type Push-Pull
Max Output Current 500μA
Polarity South Pole
Polarization South Pole
Current - Output (Max) 500μA
Max Supply Current 10mA
Logic Function Latch
Sensing Method Hall Effect
Test Condition -30°C ~ 85°C
Sensing Range 4mT Trip, -4mT Release

Compliance

RoHS Status ROHS3 Compliant
